Strautmann Verti Mix Double K - Technical Data; General Data

Product description
2.8 Technical data
2.8.1 General data
Model Unit 1300 DK 1500 DK 1800 DK 2100 DK
Permissible laden weight kg 11800 12000
Admissible axle load kg 10000 10000
Permissible vertical load kg 1800 2000
Unladen weight kg 4860 5330 6150 6610
Usable mixing capacity* (Loading capacity) m
3
13 15 18 21
Maximum operating pressure bar 210
Oil flow rate l/min 25 - 45
Minimum power required:
• without switchgear, 20 min
-1
kW (PS) 46 / 63 50 / 68 -- --
• without switchgear, 24 min
-1
kW (PS) 53 / 72 57 / 78 64 / 88 71 / 96
• with switchgear, 16 / 13 min
-1
kW (PS) 41 / 55 44 / 60 50 / 67 54 / 74
• without switchgear, 29 min
-1
kW (PS) 60 / 81 65 / 88 73 / 99 80 / 109
• with switchgear, 19 / 16 min
-1
kW (PS) 46 / 63 50 / 68 56 / 76 62 / 84
P.T.O. speed min
-1
540
Sound pressure level dB(A) 84
Figures, technical data and weights may change due to technical development and are not binding for
delivery
Tab. 1
22
Verti Mix Double K Edition 08.08
