5.6.4.1 Possible symbols and their meaning
The following paragraphs show the possible symbols on the control
unit and their meaning.
Switching on / off of control unit
Symbol Position of toggle
switch
Control unit
0 (OFF)
top
(latch-in design)
Off
(green control lamp
does not light up)
I (ON)
bottom
(latch-in design)
On
(green control lamp
lights up)
Open / Close discharge door
Symbol Position of key button Front discharge door
top
(touch-control)
open
Neutral position
Action stops
bottom
(touch-control)
close
top
(touch-control)
Front / Rear
open
Neutral position
Action stops
bottom
(touch-control)
Front / Rear
close
