Structure and Functions
5.1.5 Counter-cutters
The use of the counter-cutters (1) allows finer
chopping and faster mixing of highly-structured
fodder components.
The counter-cutters:
• are e.g. used for chopping and mixing
round or cuboid bales,
• can be extended into the mixing container
by sticking bolt (2) in 4 possible positions,
• are working the more effectively, the further
the counter-cutters are extended into the
mixing container,
• are, as a standard feature, manually
extended into the mixing container or
retracted.
Fig. 25
Optional equipment:
The counter-cutters (1) may be equipped with a
hydraulic cylinder (2).
The hydraulic cylinders:
• permit the remotely controlled extension
and retraction of the counter-cutters,
• can be extended into the mixing container
by sticking bolt (3) in 4 possible positions,
• are operated from the tractor:
ο directly via a double-acting control
device of the tractor (standard
equipment),
ο via a hand lever (optional extra),
ο via the Bowden cable (optional extra),
ο via electro-hydraulic control (control
unit) (optional equipment).
Fig. 26
