Product description
2.9 Required tractor equipment
For proper operation of the machine, the tractor employed must fulfil
the following requirements:
Tractor engine power
To the power required see chapter "Technical data", page 22.
Electrics
Battery voltage:
• 12 V (Volt)
Socket for lighting:
• 7-pin
Socket for control unit:
• 3-pin (DIN 9680). The supply lead of the 3-pin socket should
have a cable cross-section of at least 4 mm².
Hydraulics
• Check the suitability of the hydraulic oil before connecting the
machine to the hydraulic system of your tractor. If necessary
contact the agricultural machine specialist when you check the
suitability of the hydraulic oil.
• Do not mix mineral oil with bio-oil.
Maximum operating pressure:
• 210 bar
Hydraulic pump power ratio
• At least 25 l/min and maximum 45 l/min at 180 bar
Machine hydraulic oil:
• ATF hydraulic oil
For some hydraulic components a choice from a variety of coupling
options is possible:
• a double-acting control device,
• to a single-acting control device and a free return line directly
into the hydraulic oil tank of the tractor.
We recommend a single-acting control device and a free return line.
The hydraulic oil flows back into the hydraulic control tank of the
tractor through the free return line with a low pressure. A free return
reduces hydraulic oil temperature rise.
The hydraulic hose lines are colour-flagged on the hydraulic plugs:
• Pressure lines (forward P) are marked red,
• Return lines (return T) are marked blue.
Verti Mix Double K Edition
25
08.08
