Product description
Operating via direct tractor connection (standard equipment)
Hydraulic components: Control units required on the traktor:
• Discharge door: • 1 double-acting control unit
• Hydraulic support stand: • 1 double-acting control unit
• Hydraulic counter-cutters: • 1 double-acting control unit
• Hydraulic motor for
crossover conveyor:
Options:
• 1 double-acting control unit or
• 1 single-acting control unit and
1 pressureless return (tailback pressure in return max. 5 bar)
• Discharge conveyor for
right-hand front discharge:
• 1 double-acting control unit (extend and retract)
• Hydraulic motor for
discharge conveyor for
right-hand front discharge:
Options:
• 1 double-acting control unit or
• 1 single-acting control unit and
1 pressureless return (tailback pressure in return max. 5 bar)
• Conveyor extension: • 1 double-acting control unit (extend and retract)
Tab. 4
Operating via hand lever operating gear, bowden cable operation or electro-hydraulic control
(optional equipment)
Control units required on the
traktor:
Options:
• 1 double-acting control unit or
• 1 single-acting control unit and
1 pressureless return (tailback pressure in return max. 5 bar)
Tab. 5
Brake system
Hydraulic working brake up to
6 km/h (not registered for
driving on public roads):
• 1 single-acting control unit
Two-line service brake system: Two-line air brake system with:
• 1 service line hose coupler (red) for the supply line
• 1 service line hose coupler (yellow) for the brake line
Hydraulic service brake system
(only for export):
• 1 hydraulic clutch acc. to ISO 5676 (100 bar)
Tab. 6
Mirror
The tractor uses must be fitted with mirrors so that the danger zones
on both sides of the machine can be easily seen from the tractor cab.
