Structure and Functions
5.7.4 Unhitching the drawbar
WARNING
There is a risk of exposed persons being crushed while the
machine is being unhitched, if the uncoupled machine
accidentally rolls away!
Secure the machine so it cannot roll away before uncoupling it from
the tractor. Take note of the information in the chapter "Securing
tractor and machine against accidental starting and rolling", page 126.
5.7.4.1 Bolt coupling
1. Secure the tractor against accidental starting and rolling.
2. Secure the machine against rolling away. Take note of the
information in the chapter "Securing tractor and machine against
accidental starting and rolling", page 126.
3. Lower the support stand to support position such that the
drawbar no longer transmits any tongue load onto the tractor.
4. Disconnect the supply lines.
5. Place the hydraulic hose lines in the hose cupboard.
6. Prepare unhitching:
• Remove the coupling bolt (non-automatic bolt coupling).
• Open the hitch (automatic bolt coupling).
7. Move the tractor forward.
5.7.4.2 Tow-hook (hitch hook) and hitch ring
1. Secure the tractor against accidental starting and rolling.
2. Secure the machine against rolling away. Take note of the
information in the chapter "Securing tractor and machine against
accidental starting and rolling", page 126.
3. Lower the support stand to its support position.
4. Lower the tow-hook.
5. Move the tractor forward (approx. 25 cm).
6. Lift the tow-hook.
7. Secure the tractor against accidental starting and rolling.
8. Disconnect the supply lines.
9. Place the hydraulic hose lines in the hose cupboard.
10. Move the tractor forward.
98
Verti Mix Double K Edition 08.08
