Structure and Functions
5.1.3 Flat-type cylindrical gearing for drive unit with on-board hydraulic system
without switchgear
Optional equipment:
If the machine is equipped with an on-board
hydraulic system, the gear pump (1) generates
the operating pressure required for executing the
hydraulic functions.
The gear pump (1) is powered by the flat-type
cylindrical gearing (2) with the PTO drive shaft
powered.
Fig. 22
