Structure and Functions
Verti Mix Double K Edition
97
08.08
5.7.3.2 Tow-hook (hitch hook) and hitch ring
1. Secure the machine against rolling away.
2. Order everyone out of the danger area between the tractor and
machine before backing up to the machine.
3. Lower the tow-hook.
4. Drive as closely as possible to the machine such that the
lowered tow-hook can take up the hitch ring.
5. Lift the tow-hook to catch the hitch ring.
→ After automatic engaging, the drawbar eye is fixed between the
tow-hook and the lock (holding-down device).
6. Secure the tractor against accidental starting and rolling.
7. Ensure that the tow-hook is properly locked.
8. Connect the supply lines.
9. Release the parking brake of the machine.
10. Raise the support stand into transport position.
5.7.3.3 Hitch pin (piton-fix) and hitch ring
1. Secure the machine against rolling away.
2. Order everyone out of the danger area between the tractor and
machine before backing up to the machine.
3. Set back tractor and back up to machine.
4. Secure the tractor against accidental starting and rolling.
5. Remove the holding-down device (cross bolt) above the draw
pin.
6. Connect the supply lines.
7. Drive as closely as possible to the machine such that the draw
pin can take up the drawbar eye.
8. Lower the drawbar by means of the support stand, until the hitch
pin catches the hitch ring.
9. Secure the tractor against accidental starting and rolling.
10. Fix and secure the cross bolt above the draw pin.
11. Release the parking brake of the machine.
12. Raise the support stand into transport position.
