一般Model "A2520GE-A" EDITED: 2015/ 10/ 22
11-26
Maintenance and service/Air cleaner element
6. To install the air cleaner case (rear),
insert the three projections on the air
cleaner case (rear) into the slits on the
air cleaner case (front).
7. Install in the reverse order of removal.
! 3.6 L models and diesel engine
models
3.6 L models
1) Clips
Diesel engine models
1) Clips
1. Unsnap the two clips holding the air
cleaner case (rear).
2. Open the air cleaner case and remove
the air cleaner element.
CAUTION
If the inside of the air cleaner case is
extremely soiled (for example, by
sand), we recommend that you con-
tact a SUBARU dealer and have the
air cleaner case cleaned.
3. If you find large foreign objects such
as leaves inside the air cleaner case,
remove the foreign objects.
To Next Page
