Clutch pedal (MT models)
Check the clutch pedal free play and
reserve distance according to the main-
tenance schedule.
& Checking the clutch function
Check the clutch engagement and disen-
gagement.
1. With the engine idling, check that there
are no abnormal noises when the clutch
pedal is depressed, and that shifting into
1st or reverse feels smooth.
2. Start the vehicle by releasing the pedal
slowly to check that the engin e and
transmission smoothly couple without
any sign of slippage.
& Checking the clutch pedal
free play
1) 4 – 13 mm (0.16 – 0.51 in)
Lightly depress the clutch pedal down with
your finger until you feel resistance, and
check the free play.
If the fre e play is not wi thin proper
specification, we recomm end that you
contact your SUBARU dealer.
Replacement of brake pad
CAUTION
. If you continue to drive despite
the scraping noise from the audi-
ble brake pad wear indicator, it
will result in the need for costly
brake rotor repair or replace-
ment.
. It is recommended that you dis-
connect the vehicle battery be-
fore replacing the brake pad.
However, it is dangerous to dis-
connect the vehicle battery. We
recommend that you have your
SUBARU dealer replace the
brake pad.
Maintenance and service/Clutch pedal (MT models)
11-33
– CONTINUED –
11
