Fuse
panel
Fuse
rating
Circuit
19 15A E/G2
20 15A ETC
21 15A E/G1
22 15A AVCS
23 20A
*3
15A
*4
VB1.2
*3
INJ
*4
24 7.5A CVT SSR
25 20A TCU
26 30A BACKUP
27 7.5A ACTGS (2.5 L models)
28 25A SUB FAN
29 25A MAIN FAN
30 30A ABS SOL
31 20A AUDIO
32 25A R.DEF
33 15A BLOWER
34 15A BLOWER
35 10A F.FOG RH
36 10A F.FOG LH
37 15A R.WIPER
38 15A F.WASH
Fuse
panel
Fuse
rating
Circuit
39 30A F.WIPER
*3: Diesel engine models
*4: Petrol engine models
