Chapter 1 Netra T2000 Overview 5

FIGURE 1-5 UltraSPARC T1 Multicore Processor Block Diagram

Performance Enhancements

The server introduces several new technologies with its sun4v architecture and

multithreaded UltraSPARC T1 multicore processor.

Some of these enhancements are:

■ Large page optimization

■ Reduction on TLB misses

■ Optimized block copy

Preinstalled Solaris Operating System

The server is preinstalled with the Solaris 10 HW 3/05 Operating System (Solaris

OS), and offers the following Solaris OS features:

■ Stability, high performance, scalability, and precision of a mature 64-bit operating

system

■ Support for over 12,000 leading technical and business applications

SPARC

core

SPARC

core

SPARC

core

SPARC

core

SPARC

core

SPARC

core

SPARC

core

SPARC

core

Multithreaded pipe

Instruction

cache

Integer

pipeline

Data

cache

Crossbar

Shared L2 cache

DRAM DRAM DRAM DRAM

4 threads
