Chapter 5 Cabling the Server 71

FIGURE 5-3 System Controller Serial Connection

● Connect a Category 5 cable from the SC serial management port to the terminal

device.

▼ To Connect the SC Network Management Port

The SC network management port is marked NET MGT. It is the RJ-45 port above

the rear USB ports.

Note – This port is not operational until you configure the network settings

(through the serial management port), as detailed in “To Configure the System

Controller Network Management Port” on page 81.

SER MGT
