CHAPTER

Cabling the Server

This chapter provides instructions for cabling the server. Topics include:

■ “Data Ports and Cabling Notes” on page 67

■ “Connecting Cables” on page 69

■ “Managing Cables With the CMA” on page 75

Note – References to left and right are from your viewpoint as you face either the

front or rear of the equipment.

Data Ports and Cabling Notes

Port Locations

See FIGURE 5-1 for the locations of the ports on the server.
