Chapter 3 Mounting the Server Into a 4-Post Rack 47

10. Insert the ends of the mounting brackets into the sliding rails (FIGURE 3-29).

FIGURE 3-29 Mounting the Chassis on the Slide Rails

11. Slide the chassis into the rack.

Caution – Verify that the server is securely mounted in the rack, and that the slide

rails are locked to the mounting brackets, before continuing.

▼ To Install the Cable Management Assembly

The cable management assembly (CMA) clips into the ends of the left and right

sliding rail assemblies. No screws are necessary for mounting the CMA.
