Chapter 6 Powering On the Server 79

TTY External - Internal Loopback Test

TTY External - Internal Loopback Test, PASSED.

TTYC - Internal Loopback Test

TTYC - Internal Loopback Test, PASSED.

TTYD - Internal Loopback Test

TTYD - Internal Loopback Test, PASSED.

....................

Full VxDiag Tests - PASSED

Status summary - Status = 7FFF

VxDiag - - PASSED

POST - - PASSED

LOOPBACK - - PASSED

I2C - - PASSED

EPROM - - PASSED

FRU PROM - - PASSED

ETHERNET - - PASSED

MAIN CRC - - PASSED

BOOT CRC - - PASSED

TTYD - - PASSED

TTYC - - PASSED

MEMORY - - PASSED

MPC885 - - PASSED

Please login:

CODE EXAMPLE 6-1 Sample System Controller Output (Continued)
