SunStar SPS/E-BH6100 User Manual

73
Error Messages and Troubleshooting
88
error
code
3
4
Description
Error in the needle bar’s highest stop position
(Either after the sewing is finished or when the hand pulley
is spined by hand, the needle bar is not located in the right
position (the highest point of the needle bar))
•Rotate the hand pulley and place the thread take-up to
the highest position.
Limit error
(In case where the pattern size goes out of the size range of X, Y)
•Create the pattern again.
Cause and Troubleshooting
5
Knife motion error
•Check the solenoid and the air pressure.
•Check the sensor and the sensor plate.
6
X’s original point error
•Check the X Sensor.
•Check the X Sensor connecter.
8
Chain sewing error
(When the chain sewing setting is wrong)
•Without setting the pattern number in Set-No, set the
connection sewing at ‘On’.
9
Exceed the total number of stitches (If the total stitch
number goes beyond 300.)
•Create the pattern again.
16
Y’s original point error
•Check the Y Sensor.
•Check the Y Sensor connecter.
26
θ’s (rocking) original point error
•Check the θSensor.
•Check the θSensor connecter.
128
Encoder off line error
•Check the bad connector connection.
•Check the encoder cable.
•Check the bad connector connection.
•Check the encoder cable.
129
Main shaft motor overload
•Check the main shaft motor cable.
•Check the overload.
130
Synchronizer signal error
•Check the synchro signals.
14
Bad SPMS fan operation
·Fan checking
15
Failure in properly recognizing the main motor type
·Encoder cable and main shaft motor check
70
X Servo Step Moter Erro
•Check step X boarde
71
Y Servo Step Moter Error
•Check step Y boarde
72
θ (rocking) Servo Step Moter Error
•Check step θ boarde
60, 61
Synchronizer contact error
•Check the bad connector connection.
•Check the encoder cable.
126
Y Servo Step Moter Error
127
Encoder AB error
9999
Main Shaft Over Current Error
•Check Main Shaft board
Vol tage Over Load
Voltage Over Load
•Check board and cable
Vol tage Under Load
Voltage Over Load
•Check board and cable
•Check the bad connector connection.
•Check the encoder cable.
131
Main Shaft Over Current Error
•Check Main Shaft board
133
IPM Error
•Check Main Shaft board
