SV 971A User Manual – Appendixes
190
Table B.1.11. Display settings of the main results
Word
number
Name
Comment
0
0xnn48
[48, nn=header’s length]
1
TIME
0 – TIME result not displayed, 1 - TIME result displayed
2
Lpeak
0 – Lxpeak
1
result not displayed, 1 – Lxpeak
1
result displayed
3
Lmax
0 – Lxymax
2
result not displayed, 1 – Lxymax
2
result displayed
4
Lmin
0 – Lxymin
2
result not displayed, 1 – Lxymin
2
result displayed
5
L
0 – Lxy
2
result not displayed, 1 – Lxy
2
result displayed
6
DOSE
0 – DOSE result not displayed, 1 - DOSE result displayed
7
D_8h
0 – D_8h result not displayed, 1 - D_8h result displayed
8
LAV
0 – LAV result not displayed, 1 - LAV result displayed
9
Leq
0 – Lxyeq
23
result not displayed, 1 – Lxyeq
23
result displayed
10
LE
0 – LxyE
23
result not displayed, 1 - LxyE
23
result displayed
11
SEL8
0 – SEL8 result not displayed, 1 - SEL8 result displayed
12
E
0 – E result not displayed, 1 – E result displayed
13
E_8h
0 – E_8h result not displayed, E_8h 1 - result displayed
14
Lden
0 – Lden result not displayed, 1 - Lden result displayed
15
LEPd
0 – LEPd result not displayed, 1 - LEPd result displayed
16
PSEL
0 – PSEL result not displayed, 1 - PSEL result displayed
17
Ltm3
0 – Ltm3 result not displayed, 1 - Ltm3 result displayed
18
Ltm5
0 – Ltm5 result not displayed, 1 - Ltm5 result displayed
19
Ln
0 – Ln result not displayed, 1 - Ln result displayed
20
PTC
0 – PTC result not displayed, 1 - PTC result displayed
21
PTP
0 – PTP result not displayed, 1 - PTP result displayed
22
ULT
0 – ULT result not displayed, 1 - ULT result displayed
23
TWA
0 – TWA result not displayed, 1 - TWA result displayed
24
PrDOSE
0 – PrDOSE result not displayed, 1 - PrDOSE result displayed
25
PrTWA
0 – PrTWA result not displayed, 1 - PrTWA result displayed
26
LR1
0 – LR1 result not displayed, 1 - LR1 result displayed
27
LR2
0 – LR2 result not displayed, 1 – LR2 result displayed
28
LCA
0 – Lc-a result not displayed, 1 – Lc-a result displayed
29
OVL
0 – OVL result not displayed, 1 - OVL result displayed
30
LeqLF
0 – LeqLF result not displayed, 1 - LeqLF result displayed
…
…
…
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.10)
2
x - depends of the filter type in selected profile: A, C, Z, B, LF (cf. Tab. B.1.10)
y - depends of the detector type in selected profile: I (imp.), F (fast), S (slow) (cf. Tab. B.1.10)
3
y - only for exponential detector's type (cf. Tab. B.1.6)
Table B.1.12. Header of the statistical analysis
Word
number
Name
Comment
0
0xnn09
[09, nn=block’s length]
1
0x0307
[03=number of profiles, 07=active profiles mask]
2
0xmm0A
[0A, mm=sub-block’s length]
