SV 971A User Manual
93
13.4.3 Presentation of STIPA results
The STIPA results are grouped in one window
with the appropriate division into areas,
sources and points for the selected project.
When opening a project from the BA Assistant
application or creating a "Simple project" in
SvanPC++, the STIPA window will be opened
automatically. When opening individual SVL
files, the results pane is accessed via the
"STI" button on the toolbar.
In case of Simple projects, this window can
also be opened via the "Add available panel"
tab and selecting "STI".
STIPA results by default appear for areas, sources and points. Each point on the view is a button which,
when pressed, shows measurement results for a given point.
Each measurement has additionally a "checkbox" type which can be used to enable / disable a given
measurement - in this situation the STIPA results for the point and higher groups will be automatically
recalculated after the measurement is turned on / off.
Each point after the expansion has background noise results at the end of the measurement list.
