The HEADER format is as follows:
b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
where:
b15 - 1
b14 - 1
b13 - 0
b12 - 0,
b11 - header type:
0 - HS
1 - HE
b10 - 1
b9 - 0
b8 - 0
b15÷b8 – HS (0xC4), HE (0xCC)
b7÷b0 – length of the block
B.2.1.9. Record with GPS data
The value equal to -12288 (0xd000) denotes the undefined value.
Word number
Name
0
0xC703
1
Length
2
Quality
3
Time.Sec
4
Time.Min
5
Time.Hour
6
Date.Day
7
Date.Month
8
Date.Year
9
Latitude.Deg
10
Latitude.Min
11
Latitude.Sec
12
Latitude.MiliSec
13
Latitude.Dir
14
Longitude.Deg
15
Longitude.Min
16
Longitude.Sec
17
Longitude.MiliSec
18
Longitude.Dir
19
Altitude
20
Altitude.10
21
Speed
22
Length
23
0xCF03
…
…
