SV 971A User Manual – Appendixes
201
Table B.1.27. STIPA noise results
Word
number
Name
Comment
0
0x0062
[62, 00= block’s length in the second word]
1
BlockLength
length of the block
2
N
STIPA analysis frequency count
3..
Distortion[N]
STIPA distortion table (*100 dB)
…
reserved
Table B.1.24. File-end-marker
Word
number
Name
Comment
0
0xFFFF
file end marker
B.2 STRUCTURE OF THE FILE CONTAINING RESULTS FROM LOGGER’S FILE
SvanPC file header - cf. Tab. B.1.1.
File header - cf. Tab. B.1.2.
Unit and software specification - cf. Tab. B.1.3.
Calibration settings - cf. Tab. B.1.4.
User’s text - cf. Tab. B.1.5.
Parameters and global settings - cf. Tab. B.1.6.
Measurement trigger settings - cf. Tab. B.1.7.
Logger trigger settings - cf. Tab. B.1.8.
Wave-file recording parameters - cf. Tab. B.1.9.
Special settings for profiles - cf. Tab. B.1.10.
Display settings of the main results - cf. Tab. B.1.11.
Header of the statistical analysis - cf. Tab. B.1.12.
Header of the file from the logger - cf. Tab. B.1.13.
Contents of the file from the logger - cf. Tab. B.1.14. and the description in B.2.1.
RT60 parameters – cf. Tab. B.1.22
STIPA parameters – cf. Tab. B.1.25
B.2.1. The contents of the files in the logger
The records with the results and the records with the state of the markers as well as the records with the
breaks in the results registration are saved in the files in the logger. All results are written in dB*100.
B.2.1.1. Record with the results
The contents of the record with the results depends on the selected measurement function and the value
set in the Logger position of the Profile x and Spectrum sub-lists. The following elements can be present
(in the given sequence):
