SV 971A User Manual – Appendixes
200
5+N
M
area name length
6+N..
AreaName[M]
area name
6+N+M
PointId
point Id
7+N+M
K
source name length
8+N+M..
SourceName[K]
source name
8+N+M+
K
CalibrLevel
Calibration factor level (*10 dB)
…
reserved
Table B.1.26. STIPA results
Word
number
Name
Comment
0
0x0061
[61, 00= block’s length in the second word]
1
BlockLength
length of the block
2
STI
STI result (*100)
3
LAeq
LAeq result (*100 dB)
4
LCeq
LCeq result (*100 dB)
5
N
STIPA analysis frequency count
6
LZeq[1]
LZeq result for the first frequency (*100 dB)
7
Err1[1]
error flag of m(f1) for the first frequency (0,1)
8
Mf1[1]
result of m(f1) for the first frequency (*100 dB)
9
Err2[1]
error flag of m(f2) for the first frequency (0,1)
10
Mf2[1]
result of m(f2) for the first frequency (*100 dB)
i*5+1
LZeq[i]
LZeq result for the next frequency (*100 dB)
i*5+2
Err1[i]
error flag of m(f1) for the next frequency (0,1)
i*5+3
Mf1[i]
result of m(f1) for the next frequency (*100 dB)
i*5+4
Err2[i]
error flag of m(f2) for the next frequency (0,1)
i*5+5
Mf2[i]
result of m(f2) for the next frequency (*100 dB)
N*5+6
Flags
bit 0 – underrange flag
bit 1 – overload flag
N*5+7
STI-Measured
STI result not including Ambient Noise
…
reserved
