Technogym SYNCHRO Excite + - 700 AND 700 SP VERSION

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.2
7.1.2. 700 AND 700SP VERSION
Figure 7.1-4
Turn off th
e machine and unplug the mains lead
from the wall outlet:
1. Back off the 4 screws (a)
using a medium
Phillips screwdriver.
Figure 7.1-5
2.
Unplug the connector highlighted in the
figure at the side.
3. Remove the Display.
Figure 7.1-6
4. Back off the 2 screws (b)
, using a 8mm
hexagonal wrench, for remove the rear
support of the Display.
To reassemble the LED Display,
carry out the above steps in reverse order.
