SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 5.2
5.2. MOVING THE EQUIPMENT
To move the equipment from the packing pallet to the floor, lift as shown in the picture and then
slide it on the floor.
Given the weight of the equipment, we recommend 2 person be involved in lifting it.
AVVERTENZA: Lift the equipment by holding onto the frame and not the levers or
the control pannel. Take great care when moving the equipment and positioning it on
the ground, as it may overbalance.
1. The equipment has two fixed rear wheels. To move the equipment, lift it up slightly, as
shown in the illustration, and push it forwards and backwards.
Figure 5.2-1
After every moving, check if the equipment is flat, adjusting the left foot, as indicated
at the paragraph: 8.4. “The machine is not flat”.
2. If wheels cannot be used on the floor, move the equipment using standard lifting and
transport devices.
