Technogym SYNCHRO Excite + - DISASSEMBLING THE HAND SENSOR

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.26
7.6. DISASSEMBLING THE HAND SENSOR
Only for powered version: 700, 700SP and 700VISIO.
Figure 7.6-1
Turn off the machine and unplug the mains lead
from the wall outlet.
For each handle sensor:
1. Back off the 2 screws (a)
using a small
Phillips screwdriver.
Figure 7.6-2
2. Lift up the top sensor.
3. Remove the lower sensor.
4.
To disconnect the sensors, unplug the two
Faston indicated in the figure.
Continued in following page...
