Technogym SYNCHRO Excite + - VISIO MODELS

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 6.12
6.3.3. VISIO MODELS
A
Does the wall outlet supply the
correct voltage?
Is the power supply cable
OK?
Are the LED on the
CPU Board lit on?
Plug the machine into
a working
electrical outlet
Replace thecable
THE DISPLAY DOES
NOT ILLUMINATE
NO
YES
NO
YES
YES
NO
B
1
Are the fuses OK?
Replace the fuses
YES
NO
Continued on following page ...
