Technogym SYNCHRO Excite + - THE RESISTANCE IS INCORRECT

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 6.22
6.11. THE RESISTANCE IS INCORRECT
The machine will produce an incorrect resistance if:
• the mechanical components are not in perfect condition;
• the speed measurement is incorrect;
• the Brake Board is defective;
• the brake is defective.
Are the mechanics of the
machine in good condition?
Does the Brake Board output
the correct current to the brake
winding?
Replace the Brake Board
NO
Replace the Brake
winding
YES
THE RESISTANCE IS
INCORRECT
2
Repair the faulty
mechanical parts
NO
Carry out the "Speed
signal is Incorrect"
troubleshooting procedure
3
Carry out the Standard Setting
procedure
1
YES
