Technogym SYNCHRO Excite + - CAVI CU

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 2.14
2.9.2. CAVI CU
CU132: TGS signal cable
(Patch Conn. – Dual TGS reader)
Patch conn. Signal Colour
Dual TGS Reader
CN1
3
+12Vdc power
Black
1
5
RX
Green
2
9
TX
Black
3
1
GND
Black
8
CU128: 100/220V power signal cable
(Power entry module – Brake Board)
Power entry
module
Signal Colour
Brake board
CN4
N
NEUTRAL
Light Blue
1
F
PHASE
Brown
3
T
GROUND
Yellow/Green
5
