SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 6.31
6.14.2. HR RECEIVER (CHEST BELT)
CORRECT USE OF THE CHEST BELT: Wear the chest belt taking care the area of
contact with the body is humid in order to guarantee it proper works.
THE HR SIGNAL IS
INCORRECT
(Chest belt)
Check the Receiver Board
SW and the Grounding.
The problem persists?
Check the Receiver Board
has been correctly mounted
on the machine.
Proper placement?
OK
Mount the Receiver
Board in the right way
NO
YES
NO
1
Chest belt def ectiv e
YES
YES
YES
A
Check if it works
properly using a chest belt y ou
are sure it's ok.
Problem solv ed?
2
NO
Continued on following page ...
