Technogym SYNCHRO Excite + - Page 90

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 6.32
Check if the +5Vdc are at the
input of the Receiver Board.
Are present?
ARM/CPU Board
defective.
Replace it.
3
NO
YES
Check if the +5Vdc are at the
output of the ARM/CPU Board.
Are present?
4
NO
Replace the cable.
A
Receiver Board defective.
Replace it.
YES
Continued on following page ...
