SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.6
7.2.1.2. C-Safe board (B)
Figure 7.2-3
1. Disconnect from the ARM boa
rd the
connector highlighted in the figure.
2.
Remove the hot glue that fix the board on the
casing and remove the C-Safe board (B),
sliding it upward.
During the reassembly, use the hot
glue to fix the C-Safe board.
To reassemble the C-Safe board,
carry out the above steps in reverse order.
