Technogym SYNCHRO Excite + - CABLES; CBQ CABLES

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 2.13
2.9. CABLES
The colour of the cables can be changed, refer in particular to the Pin Out.
2.9.1. CBQ CABLES
CBQ-13: C-Safe Board cable (LED Only)
(Display Board- C-Safe Board)
Display Board
CN8
Signal Colour
C-Safe Board
CN1
1
Digital #1
Flat cable
1
…
…
…
…
14
Digital #14
Flat cable
14
CBQ32: TGS cable
(Patch Conn. – CPU / ARM Board)
ARM
Board
CN7
CPU
Board
CN19
Signal Colour Patch Conn.
1
Power +12Vdc
Brown
3
2
RX
Blue
5
6
TX
Black
9
8
GND
Red
1
