Technogym SYNCHRO Excite + - DISASSEMBLING THE FIXED HANDGRIPS

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.24
7.5. DISASSEMBLING THE FIXED HANDGRIPS
Figure 7.5-1
Turn off the machine and unplug the mains lead
from the wall outlet.
1. Back off the 6 screws (a)
with a medium
Phillip screwdriver.
Figure 7.5-2
2. Back off the 4 screws (a)
with a medium
Phillips screwdriver.
3. Lift up the display.
Figure 7.5-3
4. Loosen the 2 screws (c)
with a 8mm
hexagonal wrench.
5. Remove the upper tray bracket (d).
Continued in following page...
