Technogym SYNCHRO Excite + - DISASSEMBLING THE BATTERY

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.52
7.16. DISASSEMBLING THE BATTERY
Only for powered version: 500SP and 700SP.
Figure 7.16-1
Carry out the operations described in
paragraphs: 7.7.2. “Brake box cover guard
” and
7.7.3. “Front guards”.
1. Disconnect the 2 Faston
highlighted in the
figure
2. Remove the battery.
To reassemble the battery, carry out the above
steps in reverse order
