SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 7.20
To assemble a new keyboard:
1. Remove the backing film which protects the adhesive.
2. Insert the connector in the special slot on the display and connect it to the ARM Board.
3.
Apply the adhesive part, starting from the left and working toward the right, without bending the
keyboard.
4. Remove the protective film.
The keyboard assembly procedure can only be carried out once, because disassembly
damages the tracks and keys.
When reassembling the keyboard, make sure that none of the keys are bent or remain
pushed in.
After the reassembly of the Display, check the proper functioning of new keyboard, as
described at the paragraph: 6.1.4.1 “Man. Keyboard Test”.
