Technogym SYNCHRO Excite + - Page 28

SYNCHRO Excite +: Service & maintenance manual - rev. 7.1
Page 2.16
ELT-05: High Kit and Low Kit power supply cable
(Patch Conn. 1 CPU/ARM Board)
Patch conn. 1 Signal Colour
ARM Board: CN1
CPU Board: CN15
1
GND
Yellow/Green
Fast on/eyelet
2
GND -12V
White
2
3
GND -5V
Yellow
3
4
sensing GND + 5V
Pink
4
5
n.c.
-
5
6
+ 12 Vdc
Brown
6
7
+ 5 Vdc
Green
7
8
sensing + 5V
Grey
8
ELT-06: High Kit and Low Kit Serial cable
(Brake Board - Patch Conn. 2)
Brake Board: CN3
Signal
Colour
Patch Conn. 2
1
Digital Gnd
Orange-White
1
2
Digital Gnd
Orange
2
3
NC
Green- White
3
4
Download
Green
4
5
Reset
Blue- White
5
6
NC
Blue
6
7
485 Tx/Rx +
Brown- White
7
8
485 Tx/Rx -
Brown
8
ELT-07: Cavo comunicazione seriale fra Kit Alto e Kit Basso
(Patch Conn. 2 - CPU/ARM Board)
Patch Conn. 2 Signal Colour
ARM Board: CN9
CPU Board: CN18
1
Digital Gnd
Orange-White
1
2
Digital Gnd
Orange
2
3
NC
Green- White
3
4
Download
Green
4
5
Reset
Blue- White
5
6
NC
Blue
6
7
485 Tx/Rx +
Brown- White
7
8
485 Tx/Rx -
Brown
8
