Reference Error Codes and Warnings
Error Cod es
Error Message Description
Possible Solut
ions
E402
Error Generat
ing report in
Tek format
This error is generated
if there are no
results to
process
Check if the va
lid directory
and file name are selected
for report generation.
Check if the fil
e name
extension is .htm. Try
generating the report again
by pressing R
un button.
E403
Error Gener
ating report in
CSV forma t
This error is generated
if there are
no results to
process
Check if the
valid directory
and file names are selected
for report generation.
Check if the
file name
extension is .htm. Try
generating the report again
by pressin
g Run button
E404 No results present to
generate
report
This erro
r is generated if
there are no results present
for the USB Inrush, Droop
and Signa
l Quality Check
Reports
Press the Run button to get
the resul
ts and try again
E405
Could not generate a report
as the Eye diagram is
missing
This error is generated if
there is no eye diagram
found in
C:\TekApplica-
tions\TDSUSB2\temp
Press th
e Run button and
perform the measurements
again
E406
Could not generate report
as Waveform plot is missing
This error is generated if
there is no waveform plot
found
in C:\TekApplica-
tions\TDSUSB2\temp
Press t
he Run button and
perform the measurements
again
Eye Me
asurements
E601
The m
aximum zoom factor
has been reached
N/A
Press the Reset button or
use t
he Zoom out feature.
E602
Signal not proper, check
the signal
This is a check to confirm
the acquired waveform
Try a
cquiring the correct
waveform
Inrush Measurements
E50
1
Fin
al data point is still
above the inrush threshold
The signal has not fallen
below the Inrush threshold
le
vel
Try
acquiring the correct
waveform
E502
Li
ve Vbus Channel Voltage
value is not between
4.4 and 5.5 volts, check
t
he Vbus voltage in the
oscilloscope
The Live Vbus channel
vo
ltage value for inrush
current measurement is not
between 4.4 and 5.5 volts
Ch
eck the Vbus voltage in
the oscilloscope
E
503
Insufficient data length -
A minimum of 100 ms is
required for analysis
T
he acquired data length is
insufficient for analysis
T
ry acquiring the correct
waveform
E504
Sample rate is below the
minimum required rate of
1MS/sec
The sample rate of the
signal should be at least
1MS/sec for analysis
Increase the sample rate
TDSUSB2 Universal Serial Bus Measurements Package 157
