Model 200E Instruction Manual APPENDIX A
Setup Variable Numeric
Units
Default
Value
Value
Range
Description
MODEM_INIT — “AT Y0 &D0
&H0 &I0
S0=2 &B0
&N6 &M0 E0
Q1 &W0”
Any
character
in the
allowed
character
set. Up
to 100
character
s long.
RS-232 COM1 modem initialization
string. Sent verbatim plus carriage
return to modem on power up or
manually. Enclose value in double
quotes (") when setting from the
RS-232 interface.
RS232_MODE2 BitFlag 11 0-65535 RS-232 COM2 mode flags.
(Same settings as RS232_MODE)
BAUD_RATE2 — 115200 300,
1200,
2400,
4800,
9600,
19200,
38400,
57600,
115200
RS-232 COM2 baud rate. Enclose
value in double quotes (") when
setting from the RS-232 interface.
MODEM_INIT2 — “AT Y0 &D0
&H0 &I0
S0=2 &B0
&N6 &M0 E0
Q1 &W0”
Any
character
in the
allowed
character
set. Up
to 100
character
s long.
RS-232 COM2 modem initialization
string. Sent verbatim plus carriage
return to modem on power up or
manually. Enclose value in double
quotes (") when setting from the
RS-232 interface.
RS232_PASS Password 940331 0-
999999
RS-232 log on password.
MACHINE_ID ID 200 0-9999 Unique ID number for instrument.
GATEWAY_IP_ADDR
1
— “000.000.
000.000”
Any
string of
digits
and
decimal
points.
Gateway IP address.
INST_IP_ADDRESS
1
— “000.000.
000.000”
Any
string of
digits
and
decimal
points.
Instrument IP address.
INST_SUBNET_MASK
1
— “255.255.
255.0”
Any
string of
digits
and
decimal
points.
Instrument subnet mask.
INST_TCP_PORT
1
— 3000 1024-
65535
Instrument TCP port.
044100110 Rev A 237
