APPENDIX A Model 200E Instruction Manual
Setup Variable Numeric
Units
Default
Value
Value
Range
Description
TEST_CHAN_ID — NONE NONE,
PMT DE-
TECTOR,
OZONE
FLOW,
SAMPLE
FLOW,
SAMPLE
PRESSUR
E,
RCELL
PRESSUR
E,
RCELL
TEMP,
MANIFOL
D TEMP,
IZS
TEMP,
CONV
TEMP,
PMT
TEMP,
CHASSIS
TEMP,
HVPS
VOLTAGE
Diagnostic analog output ID.
Enclose value in double quotes (")
when setting from the RS-232
interface.
COMMAND_PROMPT — “Cmd> ” Any
character
in the
allowed
character
set. Up
to 100
character
s long.
RS-232 interface command
prompt. Displayed only if enabled
with RS232_MODE variable.
Enclose value in double quotes (")
when setting from the RS-232
interface.
REMOTE_CAL_MODE
3
— LOW LOW,
HIGH
Range to calibrate during remote
calibration. Enclose value in double
quotes (") when setting from the
RS-232 interface.
PASS_ENABLE — OFF ON, OFF ON enables passwords; OFF
disables them.
STABIL_GAS — NOX NO,
NO2,
NOX
Selects gas for stability
measurement. Enclose value in
double quotes (") when setting
from the RS-232 interface.
STABIL_FREQ Seconds 10 1-300 Stability measurement sampling
frequency.
STABIL_SAMPLES Samples 25 2-40 Number of samples in concentra-
tion stability reading.
HVPS_SET Volts 650
Warnings:
400-900
0-2000 High voltage power supply warning
limits. Set point is not used.
238 044100110 Rev A
