Model 200E Instruction Manual APPENDIX A
Setup Variable Numeric
Units
Default
Value
Value
Range
Description
RCELL_PRESS_SET In-Hg 6
Warnings:
0-15
0-100 Reaction cell pressure warning
limits. Set point is not used.
RCELL_CYCLE Seconds 10 0.5-30 Reaction cell temperature control
cycle period.
RCELL_PROP 1/ºC 1 0-10 Reaction cell PID temperature
control proportional coefficient.
RCELL_INTEG — 0.1 0-10 Reaction cell PID temperature
control integral coefficient.
RCELL_DERIV — 0 (disabled) 0-10 Reaction cell PID temperature
control derivative coefficient.
MANIFOLD_CYCLE
1
Seconds 5 0.5-30 Manifold temperature control cycle
period.
MANIFOLD_PROP
1
1/ºC 0.2 0-10 Manifold PID temperature control
proportional coefficient.
MANIFOLD_INTEG
1
— 0.1 Manifold PID temperature control
integral coefficient.
0-10
MANIFOLD_DERIV
1
— 0.5 0-10 Manifold PID temperature control
derivative coefficient.
SLOPE_CONST — 8 0.1-100 Slope constant factor to keep
visible slope near 1.
I2C_RESET_ENABLE — ON OFF, ON I
2
C bus automatic reset enable.
ALARM_TRIGGER Cycles 10 1–100 Number of valve cycles to trigger
concentration alarm.
HIGH HIGH,
MED,
LOW,
DIM
SERIAL_NUMBER — “00000000 ” Any
character
in the
allowed
character
set. Up
to 100
charac-
ters long.
Unique serial number for
instrument. Enclose value in
double quotes (") when setting
from the RS-232 interface.
Format: YYDDDNNNNS (year, Day
of Year, Number, Special)
DISP_INTENSITY — Front panel display intensity.
Enclose value in double quotes (")
when setting from the RS-232
interface.
044100110 Rev A 239
