Temptronic ThermoStream TP04300 Series User Manual

5
ROUTINE MAINTENANCE
RTD Sensor Calibration (DUT Mode)
5-38 TP04300 Series Interface & Applications Manual
10 Enter the ***High Calibration Reading***.
The High Calibration Reading is the temperature that is displayed on the
External Meter.
In the Example below, 150.0 was the High Calibration Setpoint, 151.1 was the
temperature displayed on the External Meter.
Enter the External Meter Reading.
Press “OK”.
11 A prompt will ask you if you want to save the calibration values.
Accept the new values or Restore the previous values as desired.
You will be returned to the Main Calibration Screen.
Step Action
