3
SYSTEM OPERATION
Manipulator Locks
3-6 TP04300 Series Interface & Applications Manual
Lock #4:
Head Pivot Lock
Tighten lock to clamp any horizontal pivoting (rotating, left to right, right to left) movement of
the thermal head with respect to the manipulator. When loosened, Head can be pivoted up to
90 degrees in either horizontal direction from the centerline of its mounting (on the end of the
manipulator lower arm).
Lock #4:
Head Pivot Lock
Thermal
Head
To Next Page
