Tenda AC5 User Manual

71
Parameter
Description
Please set according to your requirements.
Shared
Bandwidth for
Guests
It specifies downloading speed of guest network devices, with a unit Mbps. By
default, the speed is not limited. You can set according to your requirements.
7.2 Setting Guest Network
1. To access the configuration page, click Guest Network.
2. Guest Network: Switch to .
3. 2.4GHz WiFi Name: Change the WiFi name, which is Michael in this example.
4. 5GHz WiFi Name: Change the WiFi name, which is Michael_5G in this example.
5. Guest Network Password: Set password, which is 987654321 in this example.
6. Validity: Select from the drop-down list box, which is 4 hours in this example.
7. Shared Bandwidth for Guests: Click drop-down box, and select 2.
8. Click Save.
—End
After configuration, wireless devices, such as smart phones, connected to Michael or Michael_5G share a
downloading speed up to 2 Mbps, and can access the internet consecutively for4 hours.

Tenda AC5 Specifications

General

Antennas quantity	4
Antenna gain level (max)	5 dBi
Certification	CE/FCC/RoHS
Built-in processor	Yes
Processor frequency	1000 MHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
VPN support	L2TP/PPTP/IPSec
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
SIM card slot	No
Ethernet LAN (RJ-45) ports	3
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN
Security algorithms	WPA-PSK, WPA2-PSK, WPS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990
