PushingorTowingtheTractionUnit
IMPORTANT
Iftowinglimitsareexceeded,severedamagetothepiston(traction)
pumpmayoccur.
g186201
Figure57
1.Piston(traction)pump
2.Bypassvalve
Ifitbecomesnecessarytotoworpushthemachine,toworpushataspeed
below4.8km/h(3mph),andforaveryshortdistance.Ifyoumustmovethe
machineaconsiderabledistance(morethanafewfeet),transportitonatruckor
trailer.Thepiston(traction)pumpisequippedwithabypassvalvethatneeds
tobeloosenedfortowingorpushing(Figure57).RefertotheTractionUnit
Operator’sManualfortowingprocedures.
Reelmaster
®
5410/5510/5610Series
Page6–7
HydraulicSystem:GeneralInformation
15216SLRevC
