Toro 03606A Service Manual

SeatSwitch
g190802
Figure247
1.Mainwireharness
2.Seatswitchconnector
g190803
Figure248
1.Operatorseat3.Washer-headscrew(2each)
2.Seatswitchharness4.Seatswitch
Theseatswitchisnormallyopenandcloseswhentheoperatorisontheseat.If
thetractionsystemorreelengageswitchisengagedwhentheoperatorraises
outoftheseat,anoperatoradvisorywillbedisplayedontheInfoCenter.The
seatswitchanditselectricalconnectorarelocateddirectlyundertheoperator
seat(Figure248).T estingoftheswitchcanbedonewithoutseatremovalby
disconnectingtheswitchwirefromthemainwireharness(Figure247).
TheToroElectronicController(TEC)monitorstheoperationoftheseatswitch.
ElectricalSystem:TestingtheElectricalComponents
Page7–74
Reelmaster
®
5410/5510/5610Series
15216SLRevC
