Toro 03606A Service Manual

GeneralInformation
Thischaptergivesinformationaboutspecications,assemblyandrepairofthe
KubotaV1505-E3BandV1505-T-E3BdieselengineusedincertainReelmaster
5410,5510,and5610machines.
Mostrepairsandadjustmentsrequiretoolswhicharecommonlyavailablein
manyserviceshops.Theuseofsomespecializedtestequipmentisexplainedin
theengineservicemanualincludedattheendofthischapter.However,thecost
ofthetestequipmentandthespecializednatureofsomerepairsmaydictatethat
theworkbedoneatanenginerepairfacility.
ServiceandrepairpartsforKubotadieselenginesaresuppliedthroughyour
localToroDistributor.Ifapartslistisnotavailable,besuretoprovideyour
distributorwiththeT oromodelandserialnumber.
Operator’sManuals
TheTractionUnitOperator’sManualprovidesinformationregardingthe
operation,generalmaintenance,andmaintenanceintervalsfortheKubotadiesel
enginethatpowersyourReelmastermachine.TheKubotaOperator’sManual
includesinformationspecictotheengineusedinyourReelmaster.Referto
thesepublicationsforadditionalinformationwhenservicingthemachine.
KubotaWorkshopManual
TheenginethatpowersyourReelmastermachineisaKubotamodelV1505-E3B
orV1505-T-E3B.TheKubotaWorkshopManual,DieselEngine,05-E3BSeries
isavailablefortheseengines.Ensurethatthecorrectenginemanualisused
whenservicingtheengineonyourReelmaster.
ShuttingofftheEngine(Reelmaster5610)
IMPORTANT
Aftermowingorfullloadoperationonmachineswithaturbo-charged
engine,cooltheturbo-chargerbyallowingtheenginetorun
atlow-idlespeedfor5minutesbeforeshuttingofftheengine.
Thisallowstheturbochargerandinternalenginecomponentsto
cool-down.Failuretoallowthiscool-downperiodmayleadto
prematureturbochargerandenginefailure.
Reelmaster
®
5410/5510/5610Series
Page3–5
KubotaDieselEngine:GeneralInformation
15216SLRevC

Toro 03606A Specifications

General

Brand	Toro
Model	03606A
Category	Lawn Mower
Language	English
