Specications
KubotaGasolineEngine
Reelmaster5410-Gand5510-G
g237076
Figure42
1.Enginecoolingfan
4.Flywheel7.Alternator
2.Intakemanifold5.Startermotor
3.EngineECU6.Engineoillter
ItemDescription
Make/DesignationKubotaModelWG1605-G-E3:4-CycleOHV,
4Cylinder,WaterCooled,GasolineEngine
NumberofCylinders
4
BorexStroke79mmx78.4mm(3.11x3.09inches)
TotalDisplacement
1,573cm
3
(93.8in
3
)
FiringOrder1(gearcaseend)-3-4(ywheelend)-2
DirectionofRotationCounterclockwise(viewedfromywheel)
Fuel
Unleaded,regulargradegasoline(87
octaneminimum)
FuelInjectiontype
Electronicfuelinjection
FuelPump
12VDC,fueltankmounted
FuelTankCapacity53L(14USgallons)
Governor
Electronic
LowIdleSpeed(noload)
1,150to1,250rpm
HighIdleSpeed(noload)
2,950to3,050rpm
EngineOilAPISLorhigher
OilPumpGearDrivenTrochoidType
Crankcase-OilCapacity6.0L(6.3USqt)withFilter
CoolingSystemCapacity(includingreserve
tank)
6.6L(7USqt)
KubotaGasolineEngine:Specications
Page5–2
Reelmaster
®
5410/5510/5610Series
15216SLRevC

Toro 03606A Specifications
