GeneralInformation
ThischaptergivesinformationaboutspecicationsandrepairoftheYanmar
dieselengineusedoncertainReelmaster5410-D,5510-D,and5610-D
machines.Thegeneralmaintenanceproceduresaredescribedinthe
Operator’sManual.Detailedinformationonenginetroubleshooting,testing,
disassembly,andassemblyisidentiedintheYanmarEngineServiceManual
andTroubleshootingManual.
Additionally,someenginerepairproceduresaredescribedinthismanual.The
describedadjustmentsandrepairsrequiretoolswhicharecommonlyavailablein
manyserviceshops.SpecialtoolsaredescribedintheYanmarEngineService
Manual.Theuseofsomespecializedtestequipmentisexplained.However,
thecostofthetestequipmentandthespecializednatureofsomerepairsmay
dictatethattheworkbedoneatanenginerepairfacility.
ServiceandrepairpartsfortheYanmarenginesaresuppliedthroughyour
AuthorizedT oroDistributor.Ifthepartslistisnotavailable,provideyour
distributorwiththeT oroModelandSerialNumberofyourmachine.
TractionUnitOperatorsManual
TheOperatorsManualprovidesinformationregardingtheoperation,general
maintenance,andmaintenanceintervalsforyourmachine.Refertothe
Operator’sManualforadditionalinformationwhenservicingthemachine.
YanmarEngineServiceandTroubleshootingManuals
TheenginethatpowerscertainReelmaster5410-D,5510-Dmachinesisa
YanmarModel3TNV88C-DTRTier4Fcompliantengine.Theenginethat
powerscertainReelmaster5610machinesisaYanmarModel3TNV86CTTier
4Fcompliantengine.TheYanmarEngineServiceManualandTroubleshooting
Manualareavailablefortheseengines.Ensurethatthecorrectenginemanuals
areusedwhenservicingtheengineonyourmachine.
EngineElectronicControlUnit(ECU)
TheYanmarengineusedinReelmastermachinesusesanelectroniccontrol
unit(ECU)forenginemanagementandtocommunicatewiththemachineT oro
ElectronicController(TEC)andtheoperatorInfoCenteronthemachine.All
wireharnesselectricalconnectorsshouldbepluggedintotheECUbeforethe
machinekeyswitchisturnedfromtheOFFpositiontoeithertheONorSTART
position.TheengineECUislocatedattherightsideofthemachinenearthe
diesel-particulatelter(DPF).
IMPORTANT
DonotplugorunplugtheengineECUfor30secondsafterthe
machinekeyswitchisturnedoff.TheengineECUmayremain
energizedeventhoughthekeyswitchisintheOFFposition.
IfyoumustdisconnecttheengineECUforanyreason,ensurethatthekeyswitch
isintheOFFpositionwiththekeyremovedbeforedisconnectingtheengineECU.
Also,topreventpossibleengineECUdamagewhenweldingonthemachine,
disconnectandremovetheengineECUfromthemachinebeforewelding.
Note:AgroundwireisusedtogroundtheECUtothemachineframe.The
groundwireisconnectedtotheECUwith1oftheECUmountingscrewsand
issecuredtotheframewithaange-headscrew.
YanmarDieselEngine:GeneralInformation
Page4–6
Reelmaster
®
5410/5510/5610Series
15216SLRevC
