ReelEngageSwitch

g191000

Figure239

1.Reelengageswitch

2.Controlarm

Thereelengageswitchislocatedonthecontrolarm(Figure239)andallowsthe

cuttingunitstooperatewhenthefrontoftheswitchispressed.Anindicatorlight

ontheswitchidentieswhenthereelengageswitchisengaged.

TheTECmonitorsthepositionofthereelengageswitch(upordown).Using

inputsfromtheengageswitchandotherswitchesintheinterlocksystem,the

TECcontrolstheenergizingofthehydraulicsolenoidvalvesusedtodrivethe

cuttingunitmotors.

Note:T oraiseorlowerthecuttingunits,theseathastobeoccupied,themow

speedlimiterhastobeintheMOWposition,andthecuttingunitshavetobe

fullylowered.

TestingtheReelEngageSwitch

1.Parkthemachineonalevelsurface,lowerthecuttingunits,settheparking

brake,andshutofftheengine.

2.Beforeyoudisconnectthereelengageswitchfortesting,ensurethatyoutest

theswitchanditscircuitwiringasaTECelectricalinputwiththeInfoCenter

display;refertoUsingtheInfoCenterDisplayforTroubleshooting(page

7–28).

3.IftheInfoCenterveriesthatthereelengageswitchandcircuitwiringare

functioningcorrectly,nofurtherswitchtestingisnecessary.

4.IftheInfoCenterdeterminesthatthereelengageswitchandcircuitwiring

arenotfunctioningcorrectly,proceedwiththetest.

5.Removethecontrolarmcoverstogetaccesstothereelengageswitch;refer

toDisassemblingtheControlArm(page8–23).

6.EnsurethatthekeyswitchisintheOFFposition.Disconnectthewireharness

electricalconnectorfromthereelengageswitch.

g191001

Figure240

ElectricalSystem:TestingtheElectricalComponents

Page7–66

Reelmaster

5410/5510/5610Series

15216SLRevC
