FuelPump(MachinewithKubotaDieselEngine)
g228839
Figure277
1.Fuelpump
3.Inlettting
2.Fuel/waterseparator
4.Fuelsupplyhose
OnamachinewithaKubotadieselengine,thefuelpumpisattachedtothe
insideoftheleftsideframerailnearthefueltank(Figure277).
IMPORTANT
Whentestingfuelpump,ensurethatpumpisnotoperatedwithout
fuel.
DANGER
Becausedieselfuelishighlyammable,usecautionwhenhandling
it.Donotsmokewhiletestingthefuelpump.Donottestfuelpump
whileengineishot.Ensurethatthereisadequateventilationwhen
testing.Alwayswipeupanyspilledfuelbeforestartingtheengine.
TestingtheFuelPumpCapacity
1.Parkmachineonalevelsurface,lowercuttingunits,shutofftheengine
andsettheparkingbrake.Removekeyfromkeyswitch.Raiseoperator
seatandhood.
2.Disconnectwireharnesselectricalconnectorfromtheenginefuelstop
solenoidtopreventtheenginefromstarting;refertoEngineRunSolenoid
(MachinewithKubotaDieselEngine)(page7–100).
3.Ensurefuelsupplyhosesattachedtothefuelpumpandfuelsenderinfuel
tankarefreeofobstructions.
ElectricalSystem:TestingtheElectricalComponents
Page7–110
Reelmaster
®
5410/5510/5610Series
15216SLRevC
